Chemical magnetic coupling seal
Chemical magnetic coupling seal is in principle constructed in the same way as the CHEM but with a synchronous magnetic coupling forming the shaft seal.
Chemical Magnetic Coupling Seal Principle And Advantages:
The magnetic coupling lends itself to conveying poisonous or flammable substances, as well as for operation at high system pressures.
The containment shell of the magnetic coupling can be of the double-walled type. The double wall serves heating the coupling can. The double-walled containment shell can be provided with a leakage-monitoring system for particularly critical processes. The containment shell is filled with inert gas, in order to detect damage. If this gas escapes to the inside or outside, depending upon which wall is damaged, a pressure sensor will trigger an alarm. Because one wall of the double-walled containment shell is still intact, the possibility of the hazardous medium being conveyed leaking into the environment will be eliminated.
A particular highlight of the BATTE - Magnetic Coupling is the inner magnetic rotor's separate bearing. This ensures that only torque is transferred to the pump's drive shaft. The relatively heavy weight of the inner rotor is taken up by this bearing, thus relieving the extrusion melt pump's bearings.
